Fortinet FortiAP 432G
4x4 Wi-Fi 6E, Indoor wireless AP: Tri radio, Internal antenna, 2 x 5GE RJ45 ports
Overview:
FortiAP™ access points are managed centrally by the integrated WLAN controller of any FortiGate® security appliance or through the FortiEdge Cloud provisioning and management portal. With the integration of the wireless controller functionality into the market-leading FortiGate appliance, these APs are perfect for campus and branch deployments. Fortinet’s Security Fabric enables you to easily manage wired and wireless security from a Single-pane-of-glass management console and protects your network from the latest security threats.
FortiAP 432G are enterprise class 802.11ax ruggedized indoor/outdoor AP that provides three radios for tri-band access on radio capable of four spatial streams. As a Wi-Fi 6E access point it provides 6GHz band operation, OFDMA, a 10 Gigabit Ethernet port, plus an additional 1 Gbps Ethernet port with PoE out. The integrated BLE radio can be used for beacons and locationing applications.
Note: For FAP-432G, use of the 6GHz band is subject to regional regulatory authority approval.
- 802.11ax | Tri-Radio 2.4 GHz + 5 GHz + 6 GHz | 8 External Antennas
- 4x4 MU-MIMO | Up to 1148 Mbps + 2402 Mbps + 4804 Mbps
| HARDWARE OFFERINGS | ANTENNA TYPE | INDOOR USE | OUTDOOR USE |
|---|---|---|---|
| 4x4 Ruggedized Tri-radio indoor/outdoor 11ax (6 Ghz) Capable APs | External |
Highlights
- Unified management console simplifies operations, ensuring consistency in effective policy enforcement and compliance
- Built-in foundation for zerotrust network access (ZTNA) and secure access service edge (SASE), allowing you the flexibility to easily deploy microbranches with the security you need at the edge of your network
- Wireless LAN security done right, from the leader in network security. Integrated Firewall, IPS, Application Control, and Web Filter protect the wireless LAN from the latest security threats
- Protects the network from advanced wireless threats and satisfies industry compliance such as PCI DSS
Specifications:
| FortiAP 432G | |
|---|---|
| Hardware | |
| Hardware Type | Wi-Fi 6E 4x4 MIMO Outdoor AP |
| Number of Radios | 3 + 1 BLE |
| Number of Antennas | External: x4 Dual band WiFi + x4 Tri-band WiFi and Scanning + x1 2.4GHz band BLE/ZigBee |
| Antenna Type Support | N-Type (9 total): Dual Band Antenna (4); Tri Band Antenna (4); BLE/Scan antenna (1) |
| Antenna Type and Peak Gain | Omni Directional antenna. Dual band: 5.1 dBi for 2.4GHz, 6.4 dBi for 5 GHz Tri-band: 4.9 dBi for 2.4GHz, 5.8 dBi for 5 GHz, and 6.0 dBi for 6GHz band BLE Antenna: 4.7 dBi for 2.4GHz GPS Antenna: ceramic patch circular polarized: 3.0 dBi Peak gain |
| Antenna Beam width | Wi-Fi: 2.4GHz Band: 360° Horizontal and 65° Vertical 5.0GHz Band: 360° Horizontal and 50° Vertical 6.0GHz Band: 360° Horizontal and 65° Vertical BLE: 2.4GHz Band: 225° Horizontal and 55° Vertical GPS: 1.5-1.6GHz Band: 360° Horizontal and 98° Vertical |
| Supported Frequency Bands (GHz)* | 2.4-2.484GHz 5.15-5.25GHz 5.25-5.35GHz 5.47-5.725GHz 5.725-5.85GHz 5.925–6.425GHz 6.425-6.525GHz 6.525–6.875GHz 6.875–7.125GHz |
| Radio 1 Capabilities | Frequency band: 2.4GHz, Channel width: 20/40MHz, Modulation: BPSK, QPSK, 64/256/1024 QAM, MIMO Chains: 4x4 Service |
| Radio 2 Capabilities | Frequency band: 5.0GHz, Channel width: 20/40/80MHz, Modulation: BPSK, QPSK, 64/256/1024 QAM, MIMO Chains: 4x4 Service |
| Radio 3 Capabilities | Frequency band: 2.4GHz, 5.0GHz, and 6.0GHz, Channel width: 20/40/80/160MHz, Modulation: BPSK, QPSK, 64/256/1024 QAM, MIMO Chains: 4X4 Service |
| Maximum Data Rate | 2.4GHz: up to 1148 Mbps, 5.0GHz: up to 2402 Mbps, 6.0GHz: up to 4804 Mbps |
| Bluetooth Low Energy Radio | Bluetooth scanning and iBeacon advertizement @10 dBm max TX power |
| Trusted Platform Module (TPM) | Yes |
| Interfaces | x1 100M/1000M/2.5G/5.0G/10G Multigigabit Ethernet (RJ45) x1 10M/100M/1000M Ethernet (RJ45) x1 Type 3.0 USB at 2.5W x1 RS-232 RJ45 Serial Port |
| Power over Ethernet (PoE) | LAN1: 802.3bt, LAN2: N/A |
| Hit-less PoE Failover | N/A |
| Simultaneous SSIDs | Up to 8 per client serving radio (7 if background scanning is enabled) |
| EAP Type(s) | EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST, EAP-TTLS/PAP |
| User/Device Authentication | WPA™, WPA2™, and WPA3™ with 802.1x or Preshared key, WEP, Web Captive Portal, MAC blacklist and whitelist |
| Maximum Tx Power (Conducted) | 2.4GHz band: 25 dBm/316 mW (2 chains combined)* 5.0GHz band: 26 dBm/400 mW (2 chains combined)* 6.0GHz band: 23 dBm/200 mW (2 chains combined@320MHz BW)* |
| Kensington Lock | Yes |
| IEEE Standards | 802.11a, 802.11b, 802.11be, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11ac, 802.11ax, 802.11mc, 802.1X, 802.3ad, 802.3at, 802.3bt, 802.3az, 802.1Q, 802.11u, 802.11w, 802.3bz |
| SSID Types Supported | Local-Bridge, Mesh, and Tunnel |
| Per Radio Client Capacity | Up to 512 clients per radio |
| Cellular Co-existence | Yes |
| LED Off Mode | Yes |
| Advanced 802.11 Features | |
| OFDMA | Yes |
| Spatial Reuse (BSS Coloring) | Yes |
| UL MU-MIMO | Yes |
| DL-MU-MIMO | Yes |
| Enhanced Target Wake Time (TWT) | Yes |
| ZeroWait DFS | No |
| Onboard Security Functions | |
| UTP Capable | In Progress |
| UTP Features | To be confirmed |
| Wireless Monitoring Capabilities | |
| Rogue Scan radio modes | Background, Dedicated |
| WIPS / WIDS radio modes | Background, Dedicated (recommended) |
| Packet Sniffer Mode | Yes |
| Spectrum Analyzer | Yes |
| Dimensions | |
| Length x Width x Height | 10.2 x 8.7 x 2.6 in (259 x 220 x 66 mm) |
| Weight | 2.65 lbs (1.2 kg) |
| Package (shipping) Weight | 5.73 lbs (2.6 kg) |
| Mounting Options | Pole, Wall |
| Included Accessories | Mounting Kit |
| Environment | |
| CPU/RAM | Quad-core ARM Cortex-A53 1.5GHz / 2 GB |
| Power Supply | 802.3bt PoE: GPI-145 or 802.3at PoE: GPI-130 or 12V, 2.5A, 30 Watt DC power supply |
| Power Consumption (Max) | 28.9 W |
| PoE Mode | 802.3bt (full mode), 802.3at (high mode), 802.3af (low mode) |
| Humidity | 5% to 90% non-condensing |
| Operating/Storage Temp. | -22°F to 122°F (-30°C to 50°C) / -40°F to 158°F (-40°C to 70°C) |
| Directives | Low Voltage Directive • RoHS |
| UL2043 Plenum Material | Yes |
| Mean Time Between Failures | >10 Years |
| IP Rating | IP67 |
| Surge Protection Built In | Yes |
| Certifications | |
| Wi-Fi Alliance Certified | Certified (Wi-Fi 7 in progress) |
| DFS | Europe, FCC, Japan, Australia, Brazil, Taiwan, India |
| Warranty | |
| Limited Lifetime Warranty | Yes |
Note: * Frequency selection, power, and some communication features may be restricted to abide by regional regulatory compliance laws.
Documentation:
Download the FortiAP Series Data Sheet (PDF).
Pricing Notes:
- All prices displayed are Ex-VAT. 20% VAT is added during the checkout process.
- 24x7 FortiCare Contract
24x7 Support, Advanced Hardware Replacement (NBD), Firmware and General Upgrades - Prices are for one year of Premium RMA support. Usual discounts can be applied.
- Annual contracts only. No multi-year SKUs are available for these services.
- Contact Fortinet Renewals team for upgrade quotations for existing FortiCare contracts.
- Pricing and product availability subject to change without notice.
